3 Phase Light Tower Generator, 60Hz, 12kW, Mitsubishi Engine

Name: 3 Phase Light Tower Generator, 60Hz, 12kW, Mitsubishi Engine
SKU: GGS-240314-LTG-02
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Introducing our high-performance 3 Phase Light Tower Generator, engineered to meet your illumination needs with precision. Operating at 60Hz, it boasts a prime power output of 12kW, ensuring ample electricity for your applications. Powered by a reliable Mitsubishi diesel engine and cooled by water, this generator guarantees dependable performance even in demanding conditions. Illuminate your work site with confidence using our robust and efficient light tower generator.

Request a quote

Detail Information

Product Name: 3 Phase Light Tower Generator
Model: GGS-12-M
Frequency: 60Hz
Engine Brand: Mitsubishi
Fuel: Diesel
Prime Power: 12kW
Voltage: 240V
Engine Type: 4 Stroke, 4 Cylinder in Line
Cooling System: Water-cooled
Alternator Type: 3 Phase, Brushless AVR

Lighting Tower	Model of Lighting Tower	GGS-10-M	GGS-12-M
	Prime Power	10kW	12kW
	Frequency	50Hz	60 Hz
	Voltage	230V	240V
	Dimension (Working Status) L × W × H	3050 × 2750 × 9076 mm
	Dimension (Transportation status) L × W × H	3700 × 1435 × 2100 mm
	Weight (No fuel)	850 Kg
	Fuel	Diesel
	Fuel Tank Capacity	115L
	Maximum Continual Working Time (one full tank fuel)	60hr
Engine	Engine Model	Mitsubishi S4L2
	Type	Inline, water-cooled, four-stroke
	Air Intake Way	Natural Aspiration
	Displacement	1.758 L
	Rotation Rated Speed	1500 rpm	1800 rpm
	Fuel Consumption（100% load）	2.25 L/H	2.65 L/H
	Governor	Mechanical
Alternator	Alternator Model	Leroy Somer LSA40VS2
	Pole	4
Features	Type	Hydraulic type
	Pitch Number	9
	Up / Down	13/25 sec
	Rotation Angle	360°
	Lamp	4*1000 W
	Type of Lights	Metal Halide Floodlight
	Total Lumen	360000
	Radiation Area	30000 m²
	Auxiliary Output Sockets	2×16 Amp
	Auxiliary Input Sockets	1×32 Amp
	Wheel	2×165R13
	Fixed Support Leg	4
	Forklift Groove	With
