1200 kW Container Generator, 50Hz, Yucai, 4 Stroke 12 Cylinder

Name: 1200 kW Container Generator, 50Hz, Yucai, 4 Stroke 12 Cylinder
SKU: GGS-240314-CGS-01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Introducing our Quality Container Generator, delivering robust power with a real output of 1200kW and an apparent power of 1500kVA. Operating at 50Hz, this generator is equipped with a reliable 4-stroke, 12-cylinder engine. Housed in a sturdy container, it ensures durability and ease of transportation. Trust in our generator for dependable and efficient power supply for your applications.

Request a quote

Detail Information

Product Name: 1200kW Container Generator
Model: GGS-1500-Y
Frequency: 50Hz
Engine Brand: Yucai
Prime Power: 1200kW, 1500kVA
Voltage: 240V, 400V
Engine Type: 4 Stroke, 12 Cylinder in Line
Cooling System: Water-cooled
Alternator Type: 3 Phase 4 Wire, Brushless, Self-Exciter, AVR

Generator Specification
Generator Model	GGS-1500-Y
Frequency	50Hz
Prime Power	1200kW / 1500kVA
Standby Power	1350kW / 1650kVA
Rated Current	2176A
Dimension (L x W x H) (mm)	5546 x 1650 x 2218
Net Weight (KG)	13112
Engine Specification
Engine Brand	Yucai
Engine Model	YC12VC2070-D31
Prime Power	1380kW /1725kVA
Standby Power	1520kW /1900kVA
Cooling System	Water Cooled
Induction System	Turbocharged & Intercooled
Fuel Supply System	Electronic Unit Pump
Number of Cylinders	Vertical, 12 Cylinder in Line
Cycle	4 Stroke
Displacement	79.17 L
Bore x Stroke	200 x 210 mm
Compression Ratio	13.5:1
Rated Speed	1500rpm
Governor Type	Electric Start
Alternator Specification
Exciting Type	Brushless, Self-Exciter, AVR
Rated Voltage	400V/230V
Wiring Type	3 Phase 4 Wire
Power Factor	0.8
Protection Grade	IP23
Insulation Class	H
