LTC OCTG Casing, API Spec 5CT, N80-Q, 7 Inch, Range 3
Model Number: DB-OCTG-36
Key Specifications / Features
China LTC OCTG Casing Manufacturer Derbo offers LTC OCTG Casing, API Spec 5CT, Material N80-Q, 7 Inch, length Range 3, W.T 25.3 lb/ft.
Detail Information
Type: OCTG Casing.
Material: N80-Q.
Size: 7 Inch.
W.T: 25.3 lb/ft.
Length: RANGE 3.
Standard: API Spec 5CT.
Ends: LTC.
Material: N80-Q.
Size: 7 Inch.
W.T: 25.3 lb/ft.
Length: RANGE 3.
Standard: API Spec 5CT.
Ends: LTC.
| Item | Tolerance | |
| OD | D<114.3mm | ±0.79mm |
| D≥114.3mm | +1%D | |
| -0.5%D | ||
| WT | -12.50% | |
| Weight | Single Lengths | +6.5%,-3.5% |
| Carload 18 144 kg (40 000 lb) or more | -1.75% | |
| Carload less than 18 144 kg (40 000 lb) | – 3,5 % | |
| Chemical Composition and Mechanical Property | |||||||||||||||||||
| Steel Grade | Type | Chemical components | Mechanical performance | Hardness Max. |
|||||||||||||||
| C | Mn | Mo | Cr | Ni(Max) | Cu(Max) | P(Max) | S(Max) | Si(Max) | Yield strength (MPa) |
Tensile strength (MPa） |
|||||||||
| Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Min. | HRC | HBW | |||||||
| N80 | Q | - | - | - | - | - | - | - | - | - | - | 0.03 | 0.03 | - | 552 | 758 | 689 | - | - |
