ALP 5L X60 X52 X42 PSL2 LSAW Pipe, 36 Inch, SCH STD, BE
Model Number: DB-CS-LSAW-1
Key Specifications / Features
China ALP 5L LSAW Pipe Manufacturer Derbo offers ALP 5L X60 X52 X42 PSL2 LSAW Pipe, 36 inch, 11.8 Meters, API 5L-2009, SCH STD, BE Ends.
Contact Supplier
Detail Information
Type: LSAW Pipe.
Material: ALP 5L X60/X52 /X42 PSL2.
OD: 36 Inch.
W.T: SCH STD.
Length: 11.8M.
Standard: API 5L-2009.
Ends: BE Ends.
Material: ALP 5L X60/X52 /X42 PSL2.
OD: 36 Inch.
W.T: SCH STD.
Length: 11.8M.
Standard: API 5L-2009.
Ends: BE Ends.
| Tolerance for wall thickness: | |
| Wall thickness mm(in) |
Tolerances mm(in) |
| Welded Pipe | |
| ≤5.0(0.197) | ±0.5(0.020) |
| ＞5.0(0.197) to＜15.0(0.591) | ±0.1 t |
| ≥15.0(0.591) | ±1.5(0.060) |
| Chemical Composition and Mechanical Property For PSL.2 | |||||||||||
| Steel Grade | Chemical components | Mechanical performance | |||||||||
| C(Max) | Mn(Max) | P | S(Max) | Tensile Strength(Min） | Yield Strength (Min) |
||||||
| Min. | Max. | psi | Mpa | psi | Mpa | ||||||
| Welded Pipe | |||||||||||
| X42 | 0.26 | 1.30 | / | 0.030 | 0.030 | 60200 | 415 | 42100 | 290 | ||
