QT450 Butterfly Control Valve, 2 Inch, CL150 LB, EPDM Seated

Name: QT450 Butterfly Control Valve, 2 Inch, CL150 LB, EPDM Seated
SKU: CNCV-240708-BFCV-02
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Our Ductile Iron QT450 Butterfly Control Valve is manufactured in a specialized plant, featuring center sealing and EPDM rubber seats for optimal performance. Designed for reliability, it operates at 2 inches (DN50) with a Class 150 LB rating and flanged ends for easy installation. Equipped with a pneumatic actuator, this valve ensures precise flow control in industrial applications requiring efficient and durable solutions.

Request a quote

Detail Information

Product Name: Ductile Iron QT450 Butterfly Control Valve
Structure: Centre Sealing
Body Material: Ductile Iron QT450
Seat Material: EPDM Rubber
Size: DN50, 2 Inch
Pressure: PN10, PN16, Class 150 LB
End Connection: Flanged
Actuation: Pneumatic Actuator

Product Range

Standards: ANSI, GB, JIS
Body Material: Ductile Iron, Carbon Steel, Stainless Steel
Seat Material: EPDM, NBR, PTFE
Size Range: 2-56 Inch, DN50-DN1400
Pressure Rating: PN10, PN16, Class 150 LB
Medium: Water, Oil, Gas
Working Temperature: -40°C to +120°C
Actuator Options: Single Acting or Double Acting Pneumatic Actuator

Pneumatic Flange Butterfly Control Valve

Valve Material: Constructed with stainless steel for durability and corrosion resistance, available in grades SS304, SS316, SS304L, and SS316L, ensuring suitability for various applications.

Actuation: It Features pneumatic operation controlled by air pressure through an actuator, with options for both double-acting and single-acting mechanisms for versatile control.

Configuration: Designed as a 2-way valve with clear inlet and outlet ports for straightforward fluid flow management.

Flange Design: Equipped with flange connections for easy installation and secure attachment to the pipeline.

Mechanism: It incorporates a butterfly mechanism with a rotating disc to regulate fluid flow, stopping flow when aligned with the pipeline and allowing flow when perpendicular.
