Lug Type Butterfly Control Valve, ASTM A351 CF8, 3 IN, CL150
Model Number: CNCV-240708-BFCV-01
Key Specifications / Features
Our Lug Type Butterfly Control Valve features a durable ASTM A351 CF8 body and EPDM rubber seat, ensuring reliable performance. Designed for precision, it operates at 3 inches (DN80), with a Class 150 LB rating and PN16 pressure rating. Equipped with pneumatic actuation, this valve excels in controlling flow with efficiency and accuracy, making it ideal for diverse industrial applications.
Detail Information
Product Name: Lug Type Butterfly Control Valve
Structure: Centre Sealing
Body Material: ASTM A351 CF8
Seat Material: EPDM Rubber
Size: DN80, 3 Inch
Pressure: PN16, Class 150 LB
End Connection: Lug End
Actuation: Pneumatic Actuator
Product Range
Standards: API 609, ANSI B16.34
Body Material: Ductile Iron, Carbon Steel, Stainless Steel
Seat Material: EPDM, NBR, PTFE
Size Range: 2-20 Inch, DN50-DN500
Pressure Rating: PN10, PN16, Class 150 LB
Medium: Water, Oil, Gas
Working Temperature: -40°C to +120°C
Actuator Options: Single Acting or Double Acting Pneumatic Actuator
Pneumatic Lug Type Control Butterfly Valve
Mechanism: It utilizes a rotating disc to control fluid flow; aligned for flow stoppage, perpendicular for flow allowance.
Valve Material: The body and disc are crafted from stainless steel options including SS304, SS316, SS304L, and SS316L, offering strength and resistance to various environments.
Actuation: Operated by air pressure through an actuator, available in both double and single action configurations for flexible control.
Configuration: A straightforward 2-way design with distinct inlet and outlet ports for efficient fluid flow management.
Lug Design: It features lug connections for easy and secure pipeline integration.
