Multi-Stage Angle Control Valve, Pneumatic, DN10-DN600
Key Specifications / Features
This angle multi-stage pressure reduction control valve is ideal for applications with high differential pressure and those prone to flash evaporation and cavitation. Designed with multi-hole cages, it offers a multi-stage pressure reduction trim that reduces internal energy and flow velocity from the first cage. By using multiple cages, the valve ensures that medium pressure stays above saturated vapor pressure, preventing flash evaporation and cavitation. Standard configuration includes an unbalanced single-seat plug, with hardened plug and seat for extended trim life. Larger sizes feature a balanced cage valve structure for optimal performance.
Request a quote
Detail Information
SPECIFICATIONS
Product Name: Multi-Stage Angle Control Valve
Size Range: DN10-DN600, 3/8 Inch - 24 Inch
Presssure Rating: PN15, PN25, PN42, Class 900 LB, Class 1500 LB, Class 2500 LB
Key Features: Cage guided unbalanced trim structure (small size), Cage guided balanced structure (large size), Multi-stage throttle valve cage combination
Body Type: Angle Type
Bonnet type: Standard type, Heat dissipation type
Flow characteristic: equal percentage, Linear, Quick Opening
Leakage class: ASME B16.104 Ⅴ(standard type metal seat), ASME B16.104 Ⅵ(shut-off soft seat)
Pipe connection type: Flange, Butt Welding
Applicable temperature range: -196°C to 550°C
Actuator type: Pneumatic Diaphragm, Pneumatic Piston, Electric Actuator
Product Name: Multi-Stage Angle Control Valve
Size Range: DN10-DN600, 3/8 Inch - 24 Inch
Presssure Rating: PN15, PN25, PN42, Class 900 LB, Class 1500 LB, Class 2500 LB
Key Features: Cage guided unbalanced trim structure (small size), Cage guided balanced structure (large size), Multi-stage throttle valve cage combination
Body Type: Angle Type
Bonnet type: Standard type, Heat dissipation type
Flow characteristic: equal percentage, Linear, Quick Opening
Leakage class: ASME B16.104 Ⅴ(standard type metal seat), ASME B16.104 Ⅵ(shut-off soft seat)
Pipe connection type: Flange, Butt Welding
Applicable temperature range: -196°C to 550°C
Actuator type: Pneumatic Diaphragm, Pneumatic Piston, Electric Actuator
