Diaphragm Control Valve, Cast Iron, 1/2-8 IN, Class 150 LB
Key Specifications / Features
The Diaphragm Control Valve operates like a pinch clamp, sealing with a flexible diaphragm against a transverse weir. It's optimal for handling sticky fluids, slurries, corrosive, and hazardous substances, ensuring leak-tight closure. Ideal for high-purity fluids, it prevents contamination. With its low-pressure design due to a large diaphragm area, it's widely used for On/Off and throttling services in industries like Waste & Water Treatment, Filtration, and Chlorination. This valve is crucial for maintaining purity in fluid handling applications, making it indispensable for systems requiring precise control and resistance to contamination.
Request a quote
Detail Information
SPECIFICATIONS
Product Name: Diaphragm Control Valve
Body Type: Rubber Lined
Size Range: 1/2 Inch - 8 Inch, DN15-DN200
Pressure: Class 150 LB, PN10
Body Material: Cast Iron ( IS 210 grade FG 200 ), Cast Steel, Other alloys on request.
Lining Material: Ebonite, PVDF, PFA, PP, EPDM, Glass etc.
Lining Hardness:
Ebonite-95° ± 5 Shore A
Natural/Neo Rubber-55° ± 5 Shore A
PTFE-Rockwell/Shore R100 D78 or
D62 Glasslining & FRP-Parcol Parcol 40 Respectively.
Leakage Rate: As per ANSI B 16.104 Class VI (100% Leak tight.)
Working Temperature: – 30°C to 80°C
FLOW CHARACTERISTICS: On/Off, Throttling
Actuator Action: Direct Acting – Normally Open ( Air to Close ) Reverse Acting – Normally Close ( Air to Open)
Air Supply: 40-50 PSIG (2.8-3.5 Kg/cm²)
Product Name: Diaphragm Control Valve
Body Type: Rubber Lined
Size Range: 1/2 Inch - 8 Inch, DN15-DN200
Pressure: Class 150 LB, PN10
Body Material: Cast Iron ( IS 210 grade FG 200 ), Cast Steel, Other alloys on request.
Lining Material: Ebonite, PVDF, PFA, PP, EPDM, Glass etc.
Lining Hardness:
Ebonite-95° ± 5 Shore A
Natural/Neo Rubber-55° ± 5 Shore A
PTFE-Rockwell/Shore R100 D78 or
D62 Glasslining & FRP-Parcol Parcol 40 Respectively.
Leakage Rate: As per ANSI B 16.104 Class VI (100% Leak tight.)
Working Temperature: – 30°C to 80°C
FLOW CHARACTERISTICS: On/Off, Throttling
Actuator Action: Direct Acting – Normally Open ( Air to Close ) Reverse Acting – Normally Close ( Air to Open)
Air Supply: 40-50 PSIG (2.8-3.5 Kg/cm²)
