RPTFE Seated Lug Butterfly Valve, API 609, 5A, 300 LB, 2 IN
Model Number: 1862222
Key Specifications / Features
As a leading provider of API 609 butterfly valves in China, we offer top-quality valves that adhere to EN 593 standards. Crafted from ASTM A890 5A material, these 2-inch (DN50) valves are rated at 300 LBS and feature a double eccentric design. They come with an RPTFE seat, a 17-4PH stem, and lug ends, ensuring reliable performance and easy installation. The lever operation allows for smooth control, making these valves ideal for various industrial applications where precision and durability are essential.
Detail Information
Double Eccentric Butterfly Valve, 2 Inch/DN50, 300 LB, A890 5A Body, Lever Operation.
Design Standard: API 609 Category B, EN 593
Body Material: ASTM A890 5A, ASTM A351 CF8M, Titanium, ASTM A216 WCB, ASTM A890 4A, ASTM A351 CF8, ASTM B148 C95800.
Nominal Size: 2 Inch, DN50
Structure: Double Offset, Double Eccentric
Nominal Class: 300 LBS, PN50
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Lever
Seat: RPTFE, PPL
End Connection: Lug
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.
Normal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged
Valve Description
1862222 High-Performance Butterfly ValveDesign Standard: API 609 Category B, EN 593
Body Material: ASTM A890 5A, ASTM A351 CF8M, Titanium, ASTM A216 WCB, ASTM A890 4A, ASTM A351 CF8, ASTM B148 C95800.
Nominal Size: 2 Inch, DN50
Structure: Double Offset, Double Eccentric
Nominal Class: 300 LBS, PN50
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Lever
Seat: RPTFE, PPL
End Connection: Lug
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Key Features
1. Long lifespan for high-frequency operation (up to a million cycles).2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.
Product Range
Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, TitaniumNormal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged
