Pressure Seal Bonnet Y Globe Valve, 2 IN, CL2500, A182 F22
Model Number: 1852054
Key Specifications / Features
We specialize in exporting high-quality Pressure Seal Bonnet Globe Valves from China, designed for superior performance and durability. Our Y-Type globe valve is crafted from forged steel and meets industry standards, including ASTM A182 F22, API 602, and ASME B16.34. With a 2-inch size and a Class 2500 pressure rating, it is engineered to handle demanding applications with ease. The pressure seal bonnet ensures a robust and leak-proof seal, enhancing reliability in high-pressure environments. The rising stem with handwheel allows for precise manual control, while the valve can also be fitted with an actuator for automatic operation if required. The Y-pattern design features an angled flow path that reduces turbulence and pressure drop, resulting in more efficient flow control. Ideal for various industrial applications, this valve offers exceptional performance and versatility.
Detail Information
API 602 Y Globe Valve, Pressure Seal Bonnet, 2 Inch, 2500 LB, ASTM A182 F22 Body, BW End.
Key Features:
Rising Stem with Handwheel
Available with Swivel, Plug, or Needle Disc
Y Pattern
OS&Y
Live Load Packing
Backseat
Compact and Robust Body Suitable for High-Temperature and High-Pressure Service
Product Line:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 Inch - 2 Inch (DN15-DN50)
Pressure Range: Class 800 LB - 4500 LB
End Connection: BW/SW/NPT
Working Temperature: -29°C - +525°C
Operation: Manual or Actuated
| Valve Description: | 1852054 Globe Valve |
| Design Standard: | API 602, ASME B16.34 |
| Nominal Size: | 2 Inch, DN50 |
| Nominal Class: | ANSI 2500 LB |
| Body Material: | ASTM A182 F22, ASTM A182 F91, ASTM A105N, ASTM A182 F11, ASTM A182 F316 |
| Bore Type: | Reduced |
| End Connection: | BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread) |
| Operation: | Handwheel |
| Structure: | Pressure Seal Bonnet, Bolted Bonnet, Welded Bonnet, Bonnetless |
| Trim Material: | ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316 |
| Face to Face: | MFG'S |
| Applications: | Chemical Processing, Water Treatment Plants, Oil and Gas Industry, HVAC Systems. |
| Test and Inspection: | API 598 |
| Flow Path: | The angled flow path reduces turbulence and pressure drop, leading to more efficient flow control. |
| Actuation: | Can be operated manually with a handwheel or automatically with an actuator, depending on the application needs. |
Key Features:
Rising Stem with Handwheel
Available with Swivel, Plug, or Needle Disc
Y Pattern
OS&Y
Live Load Packing
Backseat
Compact and Robust Body Suitable for High-Temperature and High-Pressure Service
Product Line:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 Inch - 2 Inch (DN15-DN50)
Pressure Range: Class 800 LB - 4500 LB
End Connection: BW/SW/NPT
Working Temperature: -29°C - +525°C
Operation: Manual or Actuated
