High Performance Wafer Butterfly Valve, API 609, CF8M, 10 IN, 300 LB
Model Number: 10TB3WCF8M
Key Specifications / Features
Discover top-notch performance with our 10-inch, 300-lb High-Performance Butterfly Valve. Engineered to precision, this valve features DN250, PN50 specifications, API 609 Category B compliance, and boasts an ASTM A351 CF8M Body & Disc. Equipped with an RPTFE+SS Fire-Safe Seat, RF design, and a convenient wafer style with gear operation, it ensures reliability and efficiency in every application.
Detail Information
Double Offset Butterfly Valve, High Performance, API 609, 10 inch, 300 LB, Wafer, Stainless Steel A351 CF8M body & Disc, RPTFE+SS fire safe seat, Gear Operation, Bi-directing Sealing
Valve Description:
1862026 Double Offset Butterfly Valve 10TB3WCF8M
Design Standard: API 609 Cat B
Structure: Double Offset
Nominal size: 10 Inch
Nominal class: 300 LB
End Connection: Wafer-RF
Operation: Gear Operation
Body Material: ASTM A351 CF8M
Trim Material: ASTM A351 CF8M disc, RPTFE+SS Fire Safe seat
Face to face: API 609
Test and inspection: API 598
Key Features: Long working life for frequent open/close (million cycling), Low torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure
Product Range:
Body material: WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 48 Inch (DN50 - DN800)
Pressure range: Class 150 - 300 LB
End connection: Wafer, Lug, Flanged
Working temperature: -29℃ - +120℃
Operation: Lever, Gear
Valve Description:
1862026 Double Offset Butterfly Valve 10TB3WCF8M
Design Standard: API 609 Cat B
Structure: Double Offset
Nominal size: 10 Inch
Nominal class: 300 LB
End Connection: Wafer-RF
Operation: Gear Operation
Body Material: ASTM A351 CF8M
Trim Material: ASTM A351 CF8M disc, RPTFE+SS Fire Safe seat
Face to face: API 609
Test and inspection: API 598
Key Features: Long working life for frequent open/close (million cycling), Low torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure
Product Range:
Body material: WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 48 Inch (DN50 - DN800)
Pressure range: Class 150 - 300 LB
End connection: Wafer, Lug, Flanged
Working temperature: -29℃ - +120℃
Operation: Lever, Gear
