Fully Welded Ball Valve, ASTM A105N, 10 Inch, 300 LB, API 6D

Name: Fully Welded Ball Valve, ASTM A105N, 10 Inch, 300 LB, API 6D
Brand: www.bossealvalves.com
SKU: 10BW3BA105
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Model Number: 10BW3BA105

Key Specifications / Features

Looking for a high-quality valve for your industrial applications? Check out our Full Welded Trunnion Mounted Ball Valve, built to API 6D standards with a 10-inch diameter, 300 LB pressure rating, and BW+extended Nipples. Made with a durable A105N body and A105+ENP Trim, this valve is designed to withstand even the toughest conditions. With gear operation, it's easy to use and control, making it a great choice for a wide range of applications. Invest in the best with our Full Welded Trunnion Mounted Ball Valve.

ASTM A105N Ball Valve API 6D Ball Valve Three Pieces Ball Valve Side Entry Ball Valve 10 Inch Ball Valve Class 300 LB Ball Valve

Detail Information

Full Welded Trunnion Mounted Ball Valve, API 6D, 10 inch, 300 LB, BW+extended Nipples, A105N Body, A105+ENP Trim, Gear Operation

Valve Description:
1811029 Trunnion Mounted Ball Valve 10BW3BA105
Design Standard: API 6D
Structure: Three pieces forged body, Side Entry, Welded Bonnet, Soft Seat
Nominal size: 10 Inch
Nominal class: 300 LB
Bore Type: Full Bore
End Connection: BW+extended Nipples
Operation: Gear Box
Body Material: ASTM A105N
Trim Material: A105N+ENP, DEVLON Seat
Face to face: ASME B16.10
Test and inspection: API 598, API 6D
Key Features: Double Block & Bleed (DBB), Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency sealant injection, Full welded for nature gas pipeline

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 48 Inch (DN15 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW, HUB
Working temperature: -29℃ - +150℃
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
