Axial Expansion Joint, WCB, DN2000, PN10, 80 IN, ASME B16.34

Name: Axial Expansion Joint, WCB, DN2000, PN10, 80 IN, ASME B16.34
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Discover a reliable Axial Expansion Joint supplier offering top-quality solutions. Our products feature ASTM A216 WCB construction, DN2000 size, PN10 pressure rating, ASME B16.34 compliance, and an impressive 80-inch design. With Class 150 LB certification, our Axial Expansion Joint boasts durability and resilience. Crafted with SS 321 Metal Bellow and a Flanged End design, it's perfect for high-temperature applications. Trust in our Metal Seat technology for unmatched performance.

Request a quote

Detail Information

DN2000 PN10 Axial Expansion Joint, WCB Body, SS 321 Bellow

Valve Description:
1871002 Axial Expansion Joint
Model No.: /
Design Standard: ASME B16.34
Structure: Metal Bellow
Nominal size: DN2000
Nominal class: PN10
End Connection: Flanged End
Operation: /
Body Material: ASTM A216 WCB
Trim Material: SS 321 Bellow, 1.5mm x 3 layers
Face to face: Client Request
Test and inspection: /
Key Features: Metal Seat for high temperature

Product Range:
Body material: Iron, Steel
Normal diameter: 1/2 - 80 Inch (DN15 - DN2000)
Pressure range: PN10, PN16
End connection: Flanged
Working temperature: -29℃ - +400℃
