ASTM A351 CF8M Swing Check Valve, BS 1868, 6 IN, 600 LB, RF
Key Specifications / Features
Looking for a swing check valve? Our stainless steel ASTM A351 CF8M body valve is the perfect solution. With BS 1868 and API 594 compliance, DN150 size, 6-inch diameter, Class 600 LB rating, RF connection, bolted bonnet, and trim 12, our valve is sure to meet your needs. Order now!
Request a quote
Detail Information
Stainless Steel CF8M Swing Check Valve, BS 1868, 6 inch, 600 LB, RF, CF8M body, Trim 12.
Valve Description:
Swing Check Valve
Design Standard: API 594, BS 1868
Structure: Bolted Bonnet
Nominal size: 6 Inch
Nominal class: 600 LB
Bore Type: Standard Bore
End Connection: RF (Raised Face)
Operation: /
Body Material: ASTM A351 CF8M
Trim Material: ASTM A351 CF8M+STL.6
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Swing Disc, Renewable Seat
Product Range:
Body material: Stainless Steel, Alloy Steel
Normal diameter: 2 - 32 Inch (DN50 - DN800)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -46℃ - +425℃
Operation: /
Valve Description:
Swing Check Valve
Design Standard: API 594, BS 1868
Structure: Bolted Bonnet
Nominal size: 6 Inch
Nominal class: 600 LB
Bore Type: Standard Bore
End Connection: RF (Raised Face)
Operation: /
Body Material: ASTM A351 CF8M
Trim Material: ASTM A351 CF8M+STL.6
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Swing Disc, Renewable Seat
Product Range:
Body material: Stainless Steel, Alloy Steel
Normal diameter: 2 - 32 Inch (DN50 - DN800)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -46℃ - +425℃
Operation: /
