ASTM A351 CF8C Pressure Seal Globe Valve, 10 Inch, 2500 LB
Key Specifications / Features
We Provide China Pressure Seal Globe Valves, Pressure Seal Bonnet, OS&Y, Y type, Plug Disc, 10 Inch, 2500 LB, BS 1873, ASTM A351 CF8C, Butt Weld, Gear Opt.
Request a quote
Detail Information
Product Item: Pressure Seal Globe Valve
Model No.: 10GLPY25BCF8C
Design Standard: BS 1873
Structure: Pressure Seal Bonnet, Y type, Plug Disc
Nominal size: 10 Inch
Nominal class: 2500 LB
Bore Type: Standard Bore
End Connection: BW(Butt Weld)
Operation: Gear
Body Material: ASTM A351 CF8C
Trim Material: A351 CF8C
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Plug Disc, OS&Y, Rising Handwheel, Low fugitive emission stem packing available, Renewable Seat, Connival Disc available
Product Range
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 24 Inch (DN50 - DN1200)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +400℃
Operation: Handwheel, Gear, Motor Actuator
Model No.: 10GLPY25BCF8C
Design Standard: BS 1873
Structure: Pressure Seal Bonnet, Y type, Plug Disc
Nominal size: 10 Inch
Nominal class: 2500 LB
Bore Type: Standard Bore
End Connection: BW(Butt Weld)
Operation: Gear
Body Material: ASTM A351 CF8C
Trim Material: A351 CF8C
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Plug Disc, OS&Y, Rising Handwheel, Low fugitive emission stem packing available, Renewable Seat, Connival Disc available
Product Range
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 24 Inch (DN50 - DN1200)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +400℃
Operation: Handwheel, Gear, Motor Actuator
