ASTM A216 WCB Swing Check Valve, 24 Inch, 150 LB, API 594
Key Specifications / Features
We Provide Swing Check Valves, 24 Inch, Class 150 LB, API 594, BS 1868, ASTM A216 WCB, Cast Steel, Swing Disc, Bolted Bonnet, Raised Face, and Standard Bore.
Request a quote
Detail Information
Product Item: Swing Check Valve
Model No.: 24S1RWCB08
Design Standard: BS 1868, API 594
Structure: Bolted Bonnet, Swing type
Nominal size: 24 Inch
Nominal class: 150 LB
Bore Type: Standard Bore
End Connection: RF (Raised Face)
Operation: /
Body Material: ASTM A216 WCB
Trim Material: 1Cr13+STL, No.8
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Swing Disc, Renewable Seat
Product Range
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 32 Inch (DN50 - DN800)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +400℃
Operation: /
Model No.: 24S1RWCB08
Design Standard: BS 1868, API 594
Structure: Bolted Bonnet, Swing type
Nominal size: 24 Inch
Nominal class: 150 LB
Bore Type: Standard Bore
End Connection: RF (Raised Face)
Operation: /
Body Material: ASTM A216 WCB
Trim Material: 1Cr13+STL, No.8
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Swing Disc, Renewable Seat
Product Range
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 32 Inch (DN50 - DN800)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +400℃
Operation: /
