ASTM A216 WCB Concentric Butterfly Valve, 36 Inch, 150 LB
Key Specifications / Features
Looking for a reliable provider of concentric butterfly valves? Our valves are made from high-quality ASTM A216 WCB material and are designed to meet API 609 Cat A and EN 593 standards. Featuring PTFE lining, these valves are ideal for a variety of applications. With a size of 36 inches and DN750, they are suitable for use in large pipelines. They are rated for 150 LB and PN10 pressure and come with double-flanged ends for easy installation. Gear operation ensures precise control of valve opening and closing. Trust us to provide you with top-quality valves that meet your specific needs.
Detail Information
PTFE Lined Concentric Butterfly Valve, 36 inch, DN750, PN10, Double Flange, Ductile Iron body, CF8M Disc, PTFE lined seat, Gear Operation
Valve Description:
1861003 Concentric Butterfly Valve 30T1RDI
Design Standard: API 609 Cat A, EN 593
Structure: Concentric, PTFE Lined
Nominal size: 36 Inch/DN750
Nominal class: 150 LB/PN10
End Connection: Flanged
Operation: Gear Operation
Body Material: ASTM A216 WCB
Trim Material: A351 CF8M disc, PTFE seat
Face to face: API 609, EN558
Test and inspection: API 598
Key Features: Super Anti-corrosive PTFE seat, Low torque, Excellent control characteristics, Economical material and installation space
Product Range:
Body material: Iron, WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 72 Inch (DN50 - DN1800)
Pressure range: PN6-PN20
End connection: Wafer, Lug, Flanged
Working temperature: -29℃ - +120℃
Operation: Lever, Gear
Valve Description:
1861003 Concentric Butterfly Valve 30T1RDI
Design Standard: API 609 Cat A, EN 593
Structure: Concentric, PTFE Lined
Nominal size: 36 Inch/DN750
Nominal class: 150 LB/PN10
End Connection: Flanged
Operation: Gear Operation
Body Material: ASTM A216 WCB
Trim Material: A351 CF8M disc, PTFE seat
Face to face: API 609, EN558
Test and inspection: API 598
Key Features: Super Anti-corrosive PTFE seat, Low torque, Excellent control characteristics, Economical material and installation space
Product Range:
Body material: Iron, WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 72 Inch (DN50 - DN1800)
Pressure range: PN6-PN20
End connection: Wafer, Lug, Flanged
Working temperature: -29℃ - +120℃
Operation: Lever, Gear
