API 609 Cat A Concentric Butterfly Valve, WCB, 26 IN, 150 LB

Name: API 609 Cat A Concentric Butterfly Valve, WCB, 26 IN, 150 LB
Brand: www.bossealvalves.com
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

This 26-inch Rubber Lined Concentric Butterfly Valve is made by an API 609 Category A and EN 593 compliant manufacturer. It has a DN650 size, 150 LB and PN16 pressure ratings, and is constructed with ASTM A216 WCB material. The valve features a Wafer End connection, a CF8M Disc, and an NBR Seat.

Class 150 LB Butterfly Valve BS EN 593 Butterfly Valve API 609 Cat A Butterfly Valve PN16 Butterfly Valve Wafer Butterfly Valve ASTM A216 WCB Butterfly Valve DN650 Butterfly Valve 26 Inch Butterfly Valve

Detail Information

26 Inch Wafer End Rubber Lined Concentric Butterfly Valve, 150 LB, PN16, ASTM A216 WCB body, CF8M Disc, NBR seat, Gear Operation

Valve Description:
1861004 Concentric Butterfly Valve 26T1WWCB
Design Standard: API 609 Cat A, EN 593
Structure: Concentric
Nominal size: 26 Inch, DN650
Nominal class: 150 LB, PN16
End Connection: Wafer
Operation: Gear Operation
Body Material: ASTM A216 WCB
Trim Material: A351 CF8M disc, NBR seat
Face to face: API 609, EN558-1
Test and inspection: API 598
Key Features: Anti-corrosive rubber seat, Low torque, Excellent control characteristics, Economical material and installation space

Product Range:
Body material: Iron, WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 72 Inch (DN50 - DN1800)
Pressure range: PN6-PN20
End connection: Wafer, Lug, Flanged
Working temperature: -29℃ - +120℃
Operation: Lever, Gear
