ASTM A182 F304 Gate Valve, API 602, 1 Inch, 150 LB, RF
Model Number: 1G1RF304
Key Specifications / Features
This is a 1-inch, 150 LB Integral Flanged Forged Gate Valve, designed in accordance with API 602 standards. The valve features an RF F304 Body and Trim and is operated by a Handwheel.
Detail Information
Integral Flanged Forged Gate Valve, API 602, 1 INCH, 150 LB, RF F304 Body & Trim, Handwheel
Valve Description:
1851003 API 602 Forged Gate Valve 1G1RF304
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, OS & Y
Nominal size: 1 Inch
Nominal class: 150 LB
Bore: Regular Bore
End Connection: RF-Flanged end
Operation: Handwheel
Body Material: ASTM A182 F304
Trim Material: ASTM A182 F304
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Independent backseat, Fully guided solid wedge, Adjustable Packing Gland, Integral Flange
Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: 150-2500 LB
End connection: RF, RTJ
Working temperature: -29℃ - +400℃
Operation: Handwheel
Valve Description:
1851003 API 602 Forged Gate Valve 1G1RF304
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, OS & Y
Nominal size: 1 Inch
Nominal class: 150 LB
Bore: Regular Bore
End Connection: RF-Flanged end
Operation: Handwheel
Body Material: ASTM A182 F304
Trim Material: ASTM A182 F304
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Independent backseat, Fully guided solid wedge, Adjustable Packing Gland, Integral Flange
Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: 150-2500 LB
End connection: RF, RTJ
Working temperature: -29℃ - +400℃
Operation: Handwheel
