API 602 Y Globe Valve, ASTM A182 F316, 3/4 IN, CL1690, DN20

Name: API 602 Y Globe Valve, ASTM A182 F316, 3/4 IN, CL1690, DN20
SKU: 1852046
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Our ASTM A182 F316 Y Globe Valve, sourced from China, meets rigorous industry standards including API 602 and ASME B16.34. Designed for high-performance applications, this valve features a 3/4 inch size and is rated for Class 1690 LB pressure conditions, ensuring reliable operation under substantial pressure. The pressure seal bonnet enhances sealing integrity and durability, making it ideal for demanding environments. Its reduced bore design facilitates efficient flow control while minimizing pressure drop. The valve comes with a butt weld end, providing a secure and robust connection for various piping systems. Engineered for precision and longevity, this globe valve delivers exceptional performance and reliability for industrial applications requiring stringent standards.

Request a quote

Detail Information

API 602 Y Globe Valve, Pressure Seal Bonnet, 3/4 Inch, 1690 LB, ASTM A182 F316 Body, for Power Plant

Valve Description:

1852046 Globe Valve
Design Standard: ASME B16.34, API 602
Structure: Bolted Bonnet, Pressure Seal Bonnet, Welded Bonnet, Bonnetless
Nominal Size: 3/4 Inch, DN20
Nominal Class: CL 1690 LB
Bore Type: Reduced
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
Operation: Handwheel
Body Material: ASTM A182 F316, ASTM A182 F11, ASTM A105N, ASTM A182 F22, ASTM A182 F91
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Face to Face: MFG'S
Test and Inspection: API 598

Key Features:

1. Rising Stem with Handwheel
2. Options for Swivel, Plug, or Needle Disc
3. Y-Pattern Design
4. Outside Screw & Yoke (OS&Y) Mechanism
5. Compact, Durable Body for High-Temperature and High-Pressure Applications
6. Live Load Packing for Enhanced Seal Integrity
7. Backseat for Added Protection

Product Line:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 Inch - 2 Inch (DN15-DN50)
Pressure Range: Class 800 LB - 4500 LB
Working Temperature: -29°C - +525°C
Operation: Manual or Actuated
End Connection: BW/SW/NPT
