Lift Check Valves: BS 1868 - 1873, API 6D, ASME B16.34

Name: Lift Check Valves: BS 1868 - 1873, API 6D, ASME B16.34
SKU: LCV API 6D
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Cast Steel Lift Check Valves: BS 1868, BS 1873, API 6D, ASME B16.34, Carbon, Stainless, Alloy, Bolted Bonnet, BW, Flanged, Class 150 - 900, 1/2 - 12 Inch.

Request a quote

Detail Information

Drawing: Lift Check Valves, BS 1868 - 1873, API 6D, ASME B16.34

Valve Type: Cast Steel Lift Check Valve
Valve Size: 1/2” - 12”
Pressure Rating: Class 150 - 900
Material: Carbon Steel, Stainless Steel, Alloy Steel

Standards:

Design & Manufacture	BS 1868-1873, ASME B16.34, API 6D
Inspection & Test	API 598, API 6D
End Flange Dimension	ASME B16.5
End Flange Dimension	ASME B16.47A, MSS SP-44
End Flange Dimension	ASME B16.47B, API 605
BW End Dimension	ASME B16.25
Face to Face	ASME B16.10
Pressure-temperature Ratings	ASME B16.34
Wall Thickness Dimension	API 600 and BS 1868
