Cast Steel Gate Valves: API 600, API 6D, JIS B2073-2083

Name: Cast Steel Gate Valves: API 600, API 6D, JIS B2073-2083
SKU: GV API CS 01
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Cast Steel Gate Valves: API 600, API 6D, JIS B2073, JIS B2083, Carbon, Stainless, Alloy Steel, BW or Flanged, 150 - 2500 LB, 1/2 - 48 inch. or as required.

Request a quote PDF

Detail Information

Valve Type: Cast Steel Gate Valve.
Valve Size: 1/2” - 48”.
Pressure Rating: Class 150~Class 2500.
Standards:

Design & Manufacture	API 600, API 6D, JIS B2073-2083
Inspection & Test	API 598, API 6D, API 600, JIS B2003
End Flange Dimension	ASME B16.5, JIS B2212-2214
End Flange Dimension	ASME B16.47A, MSS SP-44
End Flange Dimension	ASME B16.47B, API 605
BW End Dimension	ASME B16.25
Face to Face	ASME B16.10, JIS B2002
Pressure-temperature Ratings	ASME B16.34

Standard Material Specifications

Parts Name		Carbon Steel to ASTM		Alloy Steel to ASTM				Stainless Steel to ASTM
1	Body	A216 WCB	A352 LCB	A217 WC1	A217 WC6	A217 WC9	A217 C5	A351 CF8	A351 CF8M	A351 CF3	A351 CF3M
8	Bonnet	A216 WCB	A352 LCB	A217 WC1	A217 WC6	A217 WC9	A217 C5	A351 CF8	A351 CF8M	A351 CF3	A351 CF3M
6	Bolts	A193 B7	A320 L7	A193 B7	A193 B16	A193 B16	A193 B16	A 193 B8	A 193 B8	A 193 B8	A 193 B8
5	Nuts	A194 2H	A194 4	A194 2H	A194 4	A194 4	A194 4	A194 8	A194 8	A194 8	A194 8
11	Gland	A182 F6a	A182 F6a	A182 F6a	A182 F6a	A182 F6a	A182 F6a	A182F304	A182 F316	A182 F304L	A182 F316L
12	Gland Flange	A216 WCB	A352 LCB	A217 WC1	A217 WC6	A217 WC9	A217 C5	A351 CF8	A351 CF8M	A351 CF3	A351 CF3M
2	Disc	A216 WCB	A352 LCB	A217 WC1	A217 WC6	A217 WC9	A217 C5	A351 CF8	A351 CF8M	A351 CF3	A351 CF3M
7	Gasket	SS Spiral Wound W/graphite, or SS Spiral Wound W/PTFE, or Reinforced PTFE
10	Packing	Braided graphite, or Die-formed graphite ring or PTFE
13	Stem Nut	Copper alloy or A439 D2
14	Hand Wheel	Ductile Iron or Carbon Steel
