3 in 1 Fruit Juice Filling and Packaging Machine
Key Specifications / Features
3 in 1 Fruit Juice Filling Machine Supplier: Stainless Steel Fruit Juice Filling and Packaging Machines, Separated Control Cabinet, Up to 24000 BHP.
Request a quote
Detail Information
3 in 1 Fruit Juice Filling and Packaging Machine
1. Washing, filling and capping, 3 in 1
2. Full automatic
3. Easy to operate and maintain
4. Materials: stainless steel
5. Separated control cabinet (touch screen, PLC)
6. CE, SGS, ISO 9001
This fruit juice filling and packaging machine is used for filling juice beverages and hot filling, and it can be used for filling different types of pet bottles. Neck-hanging technology is applied in bottle transportation. We also use a neck-hanging gripper to make bottle-size changing easily, without too much height adjustment of the equipment.
PRODUCTION CAPACITY (500ML BPH): 2000-2400, 4000-6000, 6000-10000, 10000-15000, 15000-20000, 20000-24000
FILLING PRECISION: LIQUID LEVEL±2MM
BOTTLE SIZE (MM): DIAMETER 50-100, HEIGHT 150-310
CAP SHAPE: PLASTIC SCREW CAP
WASHING WATER PRESSURE (MPA): 0.2-0.25
GAS CONSUMPTION (M3/MIN): 0.1, 0.4, 0.5, 0.6
POWER (KW): 3, 4.4, 5.2, 6.2, 7.8, 10
WEIGHT (KG): 2000, 2800, 4500, 6000, 7000, 9500
DIMENSIONS (L*W*H MM): 2080*1560*2130, 2360*1830*2250, 2900*2200*2250, 3880*2200*2250, 3700*3000*2350, 4500*3500*2400
1. Washing, filling and capping, 3 in 1
2. Full automatic
3. Easy to operate and maintain
4. Materials: stainless steel
5. Separated control cabinet (touch screen, PLC)
6. CE, SGS, ISO 9001
This fruit juice filling and packaging machine is used for filling juice beverages and hot filling, and it can be used for filling different types of pet bottles. Neck-hanging technology is applied in bottle transportation. We also use a neck-hanging gripper to make bottle-size changing easily, without too much height adjustment of the equipment.
PRODUCTION CAPACITY (500ML BPH): 2000-2400, 4000-6000, 6000-10000, 10000-15000, 15000-20000, 20000-24000
FILLING PRECISION: LIQUID LEVEL±2MM
BOTTLE SIZE (MM): DIAMETER 50-100, HEIGHT 150-310
CAP SHAPE: PLASTIC SCREW CAP
WASHING WATER PRESSURE (MPA): 0.2-0.25
GAS CONSUMPTION (M3/MIN): 0.1, 0.4, 0.5, 0.6
POWER (KW): 3, 4.4, 5.2, 6.2, 7.8, 10
WEIGHT (KG): 2000, 2800, 4500, 6000, 7000, 9500
DIMENSIONS (L*W*H MM): 2080*1560*2130, 2360*1830*2250, 2900*2200*2250, 3880*2200*2250, 3700*3000*2350, 4500*3500*2400
