7 Ton Crawler Rubber Duck Digger Excavator, Bucket 0.35 m³
Model Number: WE-230816-CE-04
Key Specifications / Features
In need of a reliable source for high-quality crawler rubber duck excavators? Look no further! Our excavators, weighing 7 tons and powered by a robust 58.8 kW engine, guarantee top-tier performance. Sporting a maximum reach of 6350 mm and a tail swing radius of 1800 mm, these machines excel in agility. Equipped with a 0.35 m³ bucket, they're your versatile solution for diverse tasks. Contact us today to explore our range of crawler rubber duck excavators and see how we can meet your needs!
Contact Supplier
Detail Information
Operating Weight: 7000 kg, 7 Tons
Engine Power: 58.8 kw
Tail Swing Radius: 1800 mm
Bucket Capacity: 0.35 m³
High Speed / Low Speed: 4.5 / 2.5 km/h
Max Digging Reach: 6350 mm
Max Digging Depth: 3570 mm
Max Digging Height: 6600 mm
Max Dumping Height: 4500 mm
Gradeability: 35 °/70%
| SPECIFICATIONS | |
| Range Of Operation | |
| Boom Length | 3300mm |
| Arm Length | 1850mm |
| Maximum Digging Reach | 6350mm |
| Maximum Digging Depth | 3570mm |
| Maximum Digging Force | 45KN |
| Maximum Digging Height | 6600mm |
| Maximum Dumping Height | 4500mm |
| Back-End Radius of Gyration | 1800mm |
| Dimensions | |
| Length*width*height) travel position | 5500*2100*2650mm |
| Distance From The arm to Rotate Machine | 3600mm |
| Axle base | 2060mm |
| Track Gauge | 1570mm |
| Width Of Crawler | 400mm |
| Ground Clearance of Counterweight | 780mm |
| Min Ground Clearance | 280mm |
| Tech Performance And Specification | |
| Angle of Rotation | 360° |
| Machine Weight | 7000kg |
| Engine Model | YUNNEI4102 |
| Rated Power | 58.8KW |
| Rated Speed | 2200r/min |
| Hydraulic System Working Pressure | 20Mpa |
| Hydraulic System Flow | 140L/min |
| Variable Piston Pump | 72ml/r |
| (High Speed/Low Speed) | 4.5/2.5km/h |
| Grade Climbing Ability | 70%/35° |
| Volume of Bucket | 0.25m3 |
| Revolution Overdrive Pressure | 20Mpa |
| Full Circle Swinging Time | 5.5s |
| Fqt Fuel Quantity | ≥4L/h |
| Capacity of The Fuel Tank | 110L |
| Hydraulic Tank Capacity | 110L |
