Ceramic Lined Knife Gate Valve, ASME B16.34, 3 Inch, 150 LB

Name: Ceramic Lined Knife Gate Valve, ASME B16.34, 3 Inch, 150 LB
SKU: WV-240109-CLV-06
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Welcome to our advanced Ceramic Lined Knife Gate Valve Plant, proudly based in China, where cutting-edge technology meets precision engineering. Our valve, meticulously designed with a 3-inch size, Class 150 LB rating, and adherence to API 6D and ASME B16.34 standards, ensures exceptional performance in diverse applications. Crafted from high-quality ASTM A216 WCB material, it guarantees durability and resilience.

Request a quote

Detail Information

Ceramic lined knife gate valve, bolted bonnet, raised flanged.

Design: API 6D, API 600, ASME B16.34, GB/T 12237.
Body: ASTM A216 WCB
Nominal size: DN80.
Nominal class: PN10.
End Connection: RF flange.
Face to face: ASME B16.10, GB/T 12221.
Test and inspection: API 598.

Product Range:
Body material: Carbon steel.
Normal diameter: 2 - 16 Inch (DN50 - DN400).
End connection: Flanged.
Pressure range: Class 150 - 600 LB.
Working temperature: -29℃ - +150℃.

Technical parameters and characteristics

Product	Ceramic knife gate valve.
Nominal diameter	2 Inch - 20 Inch.
Design temp.	Down to -29℃.
Design pressure	Class 150 - 600 LB.
Material	Carbon steel.
Design standard	API 6D, API 600, ASME 16.34, GB/T12237.
Face to face	ASME B16.10, GB/T 12221.
Connection end	Flange.
Test standard	API 598.
Package	Plywood
Application	With cinder, gray dreg, etc being angry firm to mix medium.
Model	PZ73TC
