BS 5352 Double Gate Valve, ASTM A182 F316, 3 Inch, 300 LB

As a reputable One Side Double Gate Valve Producer, we are pleased to introduce our precision-engineered valve, crafted with excellence from ASTM A182 F316 material in adherence to BS 5352 standards. Featuring a substantial 3-inch size (DN80) and a robust Class 300 LB (PN50) rating, our One Side Double Gate Valve is designed for optimal performance.

Name: Forged Steel Double Block Gate Valve
Size: DN80, 3 Inch
Pressure: Class 300 LB, PN50
Material: Forged Steel ASTM A182 F316
Standard: BS 5352
Connection: FNPT + RF Flanged
Design temp.: -196℃-573℃
Test standard: API 598, ISO 5208
Operation: Hand wheel, electric
Feature: Small size gate valve

Product Range

Size: 1/4 - 4 Inch, DN8-DN100
Pressure: Class 150-4500 LB
Standard: API 602, BS 5352, GOST, JIS, DIN, ISO
Face to face: Manufacture standard, ASME B16.10
Material: Carbon steel, Stainless steel, Alloy steel, Bronze
Connection: Socket Weld, RF Flange, FNPT, RTJ Flange
Power: Manual, Pneumatic, Solenoid, Electrical Actuated
Temperature Of Media: Medium Temperature, Normal Temperature, High Temperature, -65℉ To 450℉ (-54℃ To 232℃)
Application: Power station, petroleum, chemical engineering
Function 1: Bolted bonnet, welted bonnet, pressure seal bonnet
Function 2: Solid wedge
Function 3: Full bore, reduced bore
Function 4: Integral flanged ends, welded on flanged ends

Forged Steel Gate Valve

Our forged steel gate vales adopt solid gate, renewable seat, rising stem and non-ring hand wheel. It plays the role of pipe opening and closing ultimately through the rotation of the hand wheel to drive the lifting of gate.
