ASTM A216 WCB Globe Valve, API 600, 2 Inch, Class 600 LB, RF

Name: ASTM A216 WCB Globe Valve, API 600, 2 Inch, Class 600 LB, RF
SKU: WV-231223-AGBV-06
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a reliable API 600 Globe Valve provider, we deliver precision and performance with our cast carbon steel valve crafted from ASTM A216 WCB. With a substantial 2-inch size and a robust Class 600 LB rating, our valve is designed for dependable fluid control across diverse applications. Featuring a Rising Stem and Bolted Bonnet design, our globe valve ensures secure and efficient operation. The DN50 size and PN130 rating enhance its versatility, accommodating various pressure requirements seamlessly.

Request a quote

Detail Information

Valve description:
Globe valve, bolted bonnet, Raised flange, HW, RISING STEM
Design: API 600.
Body: ASTM A216 WCB
Nominal size: 2 INCH.
Nominal class: 600 LB.
End Connection: Raised flange.
Face to face: ASME B16.10.
Test and inspection: API 598.

Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: BW, Flanged.
Pressure range: Class 150 - 2500 LB (PN16 - PN250).
Working temperature: -29℃ - +429℃.

Technical parameters and characteristics

Product	Globe valve.
Nominal diameter	1/2 Inch - 32 Inch.
Design temp.	Down to -29℃.
Design pressure	Class 150 - 2500 LB.
Material	Carbon Steel..
Design standard	API 600.
Face to face	ASME B16.10.
OPERATION	HANDWHEEL
Connection end	BW, Flange.
Test standard	API 598.
Package	Plywood
Application	The oil and gas industry
