Welded Bonnet Y Globe Valve, 1-1/2 Inch, 1500 LB, ASTM A105

Name: Welded Bonnet Y Globe Valve, 1-1/2 Inch, 1500 LB, ASTM A105
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Get top-quality ASTM A105 carbon steel 1-1/2 inch 1500 LB Welded Bonnet Y Globe Valve from a trusted provider. This valve, conforming to API 602 standards, features a rising stem and handwheel operation, ensuring efficient and reliable performance. Designed for high-pressure applications, it's suitable for DN40 and PN250 requirements. With SW end connections, this valve guarantees seamless integration into your system for smooth operation and longevity. Trust in our expertise to deliver precision-engineered valves for your industrial needs.

Request a quote

Detail Information

Y TYPE Globe valve, carbon steel, NPS 1-1/2 Inch, 1500 LB, SW, HANDWHEEL.

Valve description:
Y TYPE Globe valve, welded bonnet, RISING STEM.
Design: API 602.
Body: ASTM A105
Nominal size: 1-1/2 Inch.
Nominal class: 1500 LB.
End Connection: SW.
Operation: Handwheel
Face to face: MFG'S.
Test and inspection: API 598.

Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 2 Inch (DN15 - DN50).
End connection: BW, SW, RF.
Pressure range: Class 150 - 2500 LB (PN16 - PN420).
Working temperature: -29℃ - +429℃.

Technical parameters and characteristics

Product	Y TYPE Globe valve.
Nominal diameter	1/2 Inch - 2 Inch.
Design temp.	Down to -29℃.
Design pressure	Class 150 - 2500 LB.
Material	Carbon Steel.
Design standard	API 602.
Face to face	MFG'S.
Operation	Handwheel
Connection end	BW, SW, RF.
Test standard	API 598.
Package	Plywood
Application	The oil and gas industry
Port	Full, reduce
