Vacuum-isolating Gate Valve, DN50, PN16, ASTM A216 WCB, RF

Name: Vacuum-isolating Gate Valve, DN50, PN16, ASTM A216 WCB, RF
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Explore our premium Vacuum-isolating Gate Valve, designed for optimal performance. This 2-inch valve, with a Class 300 LB rating and DN50 size, adheres to international standards such as ASTM A216 WCB and GB/T 12234-2007. Crafted from high-quality Carbon Steel, it features a Bolted Bonnet and Raised Flanged Ends for secure and efficient operation. Trust in the reliability of our valves for your industrial needs.

Request a quote

Detail Information

Vacuum-isolating gate valve, carbon steel, bolted bonnet, DN50, PN16, WCB, RF.

Valve description:
Vacuum-isolating gate valve, bolted bonnet, Raised flange.
Design: GB/T 12234-2007.
Body: ASTM A216 WCB
Nominal size: DN50.
Nominal class: PN16.
End Connection: RF.
Face to face: GB/T 12221.
Test and inspection: JB/T 9092.

Product Range:
Body material: Carbon Steel.
Normal diameter: DN50 - DN800.
End connection: BW, Flanged.
Pressure range: PN10 - PN160.
Working temperature: -29℃ - +429℃.

Technical parameters and characteristics

Product	Vacuum-isolating gate valve.
Nominal diameter	DN50 - DN800.
Design temp.	Down to -29℃.
Design pressure	PN16 - PN160.
Material	Carbon Steel.
Design standard	GB/T 12234.
Face to face	GB/T 12221.
Connection end	BW, Flange.
Test standard	JB/T 9092.
Package	Plywood
Application	Water, Vacuum
