Three-piece Ball Valve, API 6D, ASTM A216 WCB, 20 IN, 300 LB

Name: Three-piece Ball Valve, API 6D, ASTM A216 WCB, 20 IN, 300 LB
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Explore our premium range of three-piece ball valves. Manufactured with precision using ASTM A216 WCB carbon steel, these valves are built to perform. With a size of 20 inches, Class 300 LB rating, DN500, and PN50 pressure rating, our bolted bonnet, floating-type valves are engineered for reliability. Featuring RF end connections and gear operation, these ball valves ensure seamless flow control.

Request a quote

Detail Information

Ball valve, carbon steel, NPS 20, 300 LB, WCB, RF, Floating.

Valve description:
Ball valve, carbon steel, bolted bonnet, three-pieces
Design: API 6D.
Body: ASTM A216 WCB
Nominal size: 20 Inch.
Nominal class: 300 LB.
End Connection: RF.
OPERATION: GEAR
Test and inspection: API 598.

Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: BW, Flange (RF,RTJ).
Pressure range: 150 - 2500 LB (PN16 - PN420).
Working temperature: -29℃ - +429℃.

Technical parameters and characteristics

Product	Ball valve.
Nominal diameter	1/2 - 32 Inch.
Design temp.	Down to -29℃.
Design pressure	Class 150 - 2500 LB.
Material	Carbon Steel.
Design standard	API6D.
Face to face	ASME B16.10.
OPERATION	LEVER, GEAR
Connection end	BW, Flange (RF, RTJ).
Test standard	API 598.
Package	Plywood
Application	The oil and gas industry
