Screw Thread Ball Valve, A105, 1/2 IN, 800 LB, API 608
Key Specifications / Features
We Provide Screw Thread Floating Ball Valves, ASTM A105 Forged Steel Two-Piece Soft Seal Floating Ball Valves with Lock, 1/2 Inch, DN15, 800 LB, API 608.
Request a quote
Detail Information
Forged Steel Two-Piece Screw Thread Floating Ball Soft Seal With Lock Ball Valve
Name: 2 Piece Ball Valve
Standard: API 608
Size: 1/2 Inch, DN15
Pressure: Class 800 LB
Material: ASTM A105
Temperature Of Media: -29℃ To 120℃
Product Range
Size: 1/4 -4 Inch, DN8-DN100
Pressure: Class 150, 300, 600, 900, 1500, 2500 LB
Seat Material: PTFE, RPTFE, Devlon, Nylon, Peek
Connection: NPT, Threaded, Female, RF, RTJ, SW
Uses:
Commonly used in standard applications where a study valve is required and a reduced flow is not important to the application.
Advantages: A One-piece ball valve is known for its low cost and Robust design. Low chance of leaking, since there are no body joints.
Thread: Typical for threaded ball valves, the 1 piece comes with female NPT threads on both ports.
Presure Rating: Pressure rated at 1000 PSI WOG (Water, Oil, Gas).
Port: Designed with a reduced port, also known as a standard port.
Material: Our 1-piece valves are made with quality grade 316 stainless steel.
Name: 2 Piece Ball Valve
Standard: API 608
Size: 1/2 Inch, DN15
Pressure: Class 800 LB
Material: ASTM A105
Temperature Of Media: -29℃ To 120℃
Product Range
Size: 1/4 -4 Inch, DN8-DN100
Pressure: Class 150, 300, 600, 900, 1500, 2500 LB
Seat Material: PTFE, RPTFE, Devlon, Nylon, Peek
Connection: NPT, Threaded, Female, RF, RTJ, SW
Uses:
Commonly used in standard applications where a study valve is required and a reduced flow is not important to the application.
Advantages: A One-piece ball valve is known for its low cost and Robust design. Low chance of leaking, since there are no body joints.
Thread: Typical for threaded ball valves, the 1 piece comes with female NPT threads on both ports.
Presure Rating: Pressure rated at 1000 PSI WOG (Water, Oil, Gas).
Port: Designed with a reduced port, also known as a standard port.
Material: Our 1-piece valves are made with quality grade 316 stainless steel.
| Item | Valve |
| Type | Ball Valve |
| Certification | CE,TS,ISO9001,ISO14001,ISO18001 |
| Brand | VERVO |
| Model number | Q11F-800LB |
| Power | Manual |
| Port Size | 1/2" |
| Structure | Ball,Floating |
| Pressure | high perssure |
| Temperature | -29℃-200℃ |
| Medium | Water,Steam,Oil |
| Connection form | screw thread |
| Body material | Forged steel |
| Seal material | Gasket |
| Feature | Full Diameter |
