Reduced Port Globe Valve, 1-1/2 Inch, 800 LB, API 602, A105N

Name: Reduced Port Globe Valve, 1-1/2 Inch, 800 LB, API 602, A105N
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Discover our top-quality Reduced Port Carbon Steel Globe Valve: 1-1/2 Inch, DN40, Class 800 LB, PN130. Manufactured to API 602 and ASTM A105N standards, it features a Bolted Bonnet, OS & Y design, BB configuration, SW End, and Handwheel operation. Trust us for reliable industrial valve solutions.

Request a quote

Detail Information

Globe valve, carbon steel, NPS 1-1/2, 800 LB, A105N.

Valve description:
Globe valve, bolted bonnet, reduced port, OS & Y, BB.
Design: API 602.
Body: ASTM A105N
Nominal size: 1-1/2 Inch.
Nominal class: 800 LB.
End Connection: SW.
Operation: Handwheel
Face to face: MFG.
Test and inspection: API 598.

Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 2 Inch (DN15 - DN50).
End connection: Flange (FF, RF, RTJ), BW, SW, Threaded.
Pressure range: Class 150 - 2500 LB (PN16 - PN420).
Working temperature: -29℃ - +429℃.

Technical parameters and characteristics

Product	Globe valve.
Nominal diameter	1/2 Inch - 2 Inch.
Design temp.	Down to -29℃.
Design pressure	Class 150 - 2500 LB.
Material	Carbon Steel.
Design standard	API 602.
Face to face	MFG.
Operation	Handwheel
Connection end	Flange (FF, RF, RTJ), BW, SW, Threaded.
Test standard	API 598.
Package	Plywood
Application	The oil and gas industry
