Bolted Bonnet Globe Valve, Vacuum-isolating, DN25, PN16, BW

Name: Bolted Bonnet Globe Valve, Vacuum-isolating, DN25, PN16, BW
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Explore high-quality Bolted Bonnet Globe Valves at our factory, available in various specifications: DN25, 1 Inch, PN16, Class 150 LB. Crafted from ASTM A216 WCB Carbon Steel and compliant with GB/T 12235-2007 standards. Features a user-friendly Handwheel, Butt Weld (BW) End, and a wide size range from DN15 to DN300. Suitable for diverse applications with pressure ratings ranging from PN16 to PN100.

Request a quote

Detail Information

Vacuum-isolating Globe valve, Carbon steel, DN25, PN16, BW.

Valve description:
Vacuum-isolating Globe valve, bolted bonnet, BW.
Design: GB/T 12235-2007.
Body: ASTM A216 WCB
Nominal size: DN25
Nominal class: PN16.
End Connection: BW.
Operation: Handwheel
Face to face: GB/T 12221.
Test and inspection: JB/T 9092-1999.

Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 12 Inch (DN15 - DN300).
End connection: BW, Flange.
Pressure range: Class 150 - 600 LB (PN16 - PN100).
Working temperature: -29℃ - +429℃.

Technical parameters and characteristics

Product	Vacuum-isolating Globe valve.
Nominal diameter	1/2 - 12 Inch.
Design temp.	Down to -29℃.
Design pressure	PN16 - PN100.
Material	Carbon Steel.
Design standard	GB/T 12235-2007.
Face to face	GB/T 12221.
Operation	Gear, handwheel
Connection end	BW, Flange.
Test standard	JB/T 9092-1999.
Package	Plywood
Application	Water, steam and air
