ASTM A350 LF2 Dual Plate Check Valve, 4 IN, 2500 LB, API 6D
Key Specifications / Features
Discover our premium ASTM A350 LF2 Dual Plate Check Valve, designed for optimal performance. This valve, boasting a 4-inch size (DN100) and 100mm dimension, is built to withstand the high pressures of Class 2500 LB (PN420). It adheres to industry standards including API 594 and API 6D, ensuring reliability and compliance. Crafted from forged carbon steel, this swing-type valve guarantees durability and efficiency. Explore its seamless operation and secure clamp end design for your industrial needs.
Detail Information
API 6D Dual Plate Check Valve
Design Standard: API 594, API 6D
Body Material: Forged Steel, Carbon Steel, ASTM A350 LF2
Nominal Diameter: 4 Inch, DN100, 100 MM
Pressure: Class 2500 LB
End Connection: CLAMP End
Face To Face: ASME B16.10
Test And Inspection: API 598
Product Range
Body Material: Carbon steel, Stainless steel, Alloy steel.
Normal diameter: 1/2 - 48 Inch (DN15-DN1200).
End connection: Wafer, Lug, Clamp, Flanged.
Pressure range: 150 - 2500 lbs(PN10-PN420).
Working temperature: -196℃ - +560℃.
Design Standard: API 594, API 6D
Body Material: Forged Steel, Carbon Steel, ASTM A350 LF2
Nominal Diameter: 4 Inch, DN100, 100 MM
Pressure: Class 2500 LB
End Connection: CLAMP End
Face To Face: ASME B16.10
Test And Inspection: API 598
| Item | Double Disc Swing Check Valve |
| Certification | ISO 9001, ISO 14001, ISO 18001, TS, CE, API |
| Brand | VERVO |
| Model number | H71W-2500LB-4INCH |
| Port Size | 4Inch, DN100, 100mm |
| Structure type | Swing Check Valve/Double Disc Swing Check Valve |
| Pressure | 2500 LB |
| Temperature | -46 - 325 Degree |
| Connection form | Clamped Type End |
| Material | Forged Steel Low-Temperature Carbon Steel A350 LF2 |
| Feature | Easy disassembly |
Product Range
Body Material: Carbon steel, Stainless steel, Alloy steel.
Normal diameter: 1/2 - 48 Inch (DN15-DN1200).
End connection: Wafer, Lug, Clamp, Flanged.
Pressure range: 150 - 2500 lbs(PN10-PN420).
Working temperature: -196℃ - +560℃.
