ASTM A216 WCB Ceramic Valve, DN100, PN10, ASME B16.34, RF
Key Specifications / Features
Explore top-quality bolted bonnet ceramics valves from a trusted supplier. Our DN100 (4 inch) valves are designed to meet PN10 and Class 150 LB standards, following ASME B16.34 guidelines. Crafted from durable carbon steel (ASTM A216 WCB), these valves feature a non-rising stem and RF flange for optimal performance. Upgrade your industrial processes with precision and reliability.
Detail Information
Anticorrosive ceramic leave the material valve, Carbon steel, DN100, PN10, RF, FULL PORT, Non-rising stem.
Valve description:
Anticorrosive ceramics leave the material valve, bolted bonnet, raised flanged, Z644TC.
Design: GB/T 12237, ASME B16.34.
Body: ASTM A216 WCB
Nominal size: DN100.
Nominal class: PN10.
End Connection: RF flange GB/T 9113, ASME B16.5
Face to face: ASME B16.10, GB/T 12221.
Test and inspection: API 598.
Product Range:
Body material: Carbon steel.
Normal diameter: 2 - 20 Inch (DN50 - DN500).
End connection: Flanged.
Pressure range: Class 150 - 300 LB.
Working temperature: -29℃ - +200℃.
Technical parameters and characteristics
Valve description:
Anticorrosive ceramics leave the material valve, bolted bonnet, raised flanged, Z644TC.
Design: GB/T 12237, ASME B16.34.
Body: ASTM A216 WCB
Nominal size: DN100.
Nominal class: PN10.
End Connection: RF flange GB/T 9113, ASME B16.5
Face to face: ASME B16.10, GB/T 12221.
Test and inspection: API 598.
Product Range:
Body material: Carbon steel.
Normal diameter: 2 - 20 Inch (DN50 - DN500).
End connection: Flanged.
Pressure range: Class 150 - 300 LB.
Working temperature: -29℃ - +200℃.
Technical parameters and characteristics
| Product | Anticorrosive ceramics leave the material valve. |
| Nominal diameter | 2 Inch - 20 Inch. |
| Design temp. | Down to -29℃. |
| Design pressure | Class 150 - 300 LB. |
| Material | Carbon steel. |
| Design standard | GB/T 12237, ASME 16.34. |
| Face to face | ASME B16.10, GB/T 12221. |
| Connection end | Flange. |
| Test standard | API 598. |
| Package | Plywood |
| Application | Dry dust, Water. |
