ASTM A182 F304 BB Gate Valve, API 602, 1 Inch, 800 LB, SW
Key Specifications / Features
We Provide ASTM A182 F304 BB Gate Valves, ASTM A182 F304 Stainless Steel Gate Valves, Bolted Bonnet, API 602, BS 5352, 1 Inch, DN25, Class 800 LB, SW Ends.
Request a quote
Detail Information
Socket Welding full port stainless steel A182 F304 BB gate valve
Name: Forged Steel Stainless Steel Gate Valve
Media: Oli, Gas, Water
Standard: API 602, BS 5352
Size: 1 Inch, DN25
Pressure: Class 800 LB, PN130
Material: ASTM A182 F304
End Connection: Socket Weld
Feature: Full Port
Design Features:
Outside Screw and Yoke (OS&Y)
Two Piece self-aligning packing gland
Bolted bonnet with spiral-wound gasket
Integral backseat
Specifications
Basic Design: API 602, ANSI B16.34
End to End: VERVO Standard
Test & Inspection: API-598
Screwed Ends (NPT) to ANSI/ASME B1.20.1
Socket weld Ends to ASME B16.11
Butt weld Ends to ASME B16.25
End Flange: ANSI B16.5
Optional Features
Full Port or Regular Port
Extended Stem or Below Seal
Welded Bonnet or Pressure Seal Bonnet
Locking Device upon request
Manufacturing to NACE MR0175 upon request
Name: Forged Steel Stainless Steel Gate Valve
Media: Oli, Gas, Water
Standard: API 602, BS 5352
Size: 1 Inch, DN25
Pressure: Class 800 LB, PN130
Material: ASTM A182 F304
End Connection: Socket Weld
Feature: Full Port
| Model number | Z61Y-800LB-DN25 |
| Item | Forged Steel Stainless Steel Gate Valve |
| Certification | ISO9001,ISO14001,ISO18001,TS,CE,API |
| Connection form | SOCKET WELDING |
| Body material | Forged steel ASTM A182 F304 |
| Purpose | Suitable for Various industries |
| Temperature | -29-300℃ |
Design Features:
Outside Screw and Yoke (OS&Y)
Two Piece self-aligning packing gland
Bolted bonnet with spiral-wound gasket
Integral backseat
Specifications
Basic Design: API 602, ANSI B16.34
End to End: VERVO Standard
Test & Inspection: API-598
Screwed Ends (NPT) to ANSI/ASME B1.20.1
Socket weld Ends to ASME B16.11
Butt weld Ends to ASME B16.25
End Flange: ANSI B16.5
Optional Features
Full Port or Regular Port
Extended Stem or Below Seal
Welded Bonnet or Pressure Seal Bonnet
Locking Device upon request
Manufacturing to NACE MR0175 upon request
