ASTM A182 F22 Globe Valve, API 602, 1 Inch, 800 LB, NPT

Name: ASTM A182 F22 Globe Valve, API 602, 1 Inch, 800 LB, NPT
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Discover our high-quality Forged Steel Bolted Bonnet Globe Valve, designed for optimal performance. This valve features a 1-inch size and is rated at 800 LB, making it suitable for various applications. Crafted with ASTM A182 F22 material, it ensures durability and corrosion resistance. Compliant with API 602 and ASME B1.20.1 standards, this valve offers reliable operation. With NPT end connections and convenient handwheel operation, it provides easy installation and control. Upgrade your industrial processes with this reliable and efficient Forged Steel Bolted Bonnet Globe Valve.

Request a quote

Detail Information

Globe valve, forged steel, bolted bonnet, NPS 1, 800 LB, NPT, HANDWHEEL.

Valve description:
Globe valve, forged steel, F22, NPT, HANDWHEEL.
Design: API 602.
Body: ASTM A182 F22
Nominal size: 1 Inch.
Nominal class: 800 LB.
End Connection: NPT, ASME B1.20.1.
Operation: Handwheel
Face to face: MFG'S.
Test and inspection: API 598.

Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 3 Inch (DN15 - DN80).
End connection: BW, Flange.
Pressure range: 150 - 2500 LB (PN16 - PN420).
Working temperature: -29℃ - +500℃.

Technical parameters and characteristics

Product	Globe valve.
Nominal diameter	1/2 Inch - 3 Inch.
Design temp.	Down to -29℃.
Design pressure	Class 150 - 2500 LB.
Material	Forged steel.
Design standard	API 602.
Face to face	MFG'S.
Operation	Handwheel
Connection end	BW, Flange.
Test standard	API 598.
Package	Plywood
Application	The oil and gas industry
