ASTM A105N Three-piece Ball Valve, 1/2 Inch, 800 LB, API 608

Name: ASTM A105N Three-piece Ball Valve, 1/2 Inch, 800 LB, API 608
Brand: www.vervovalve.com
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Explore top-quality Carbon Steel ASTM A105N Ball Valve from a trusted supplier. This three-piece body valve features a 1/2-inch size (DN15), 800 LB (PN130) pressure rating, and complies with API 608 standards. With a bolted bonnet design, gear operation, and pipes on both sides, it ensures reliable performance for various applications.

ASTM A105N Ball Valve DN15 Ball Valve Class 800 LB Ball Valve API 608 Ball Valve Bolted Bonnet Ball Valves 1/2 Inch Ball Valve Carbon Steel Ball Valves PN130 Ball Valve

Detail Information

Ball valve, carbon steel, bolted bonnet, NPS 1/2, 800 LB, A105N, PIPE ON BOTH SIDES.

Valve description:
Ball valve, carbon steel, bolted bonnet, three-pieces
Design: API 608.
Body: ASTM A105N
Nominal size: 1/2 Inch.
Nominal class: 800 LB.
End Connection: PIPE ON BOTH SIDES.
OPERATION: GEAR
Face to face: ASME B16.10.
Test and inspection: API 598.

Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 2 Inch (DN15 - DN50).
End connection: BW, Flange, NPTF, SW.
Pressure range: Class 150 - 1500 LB (PN16 - PN320).
Working temperature: -29℃ - +429℃.

Technical parameters and characteristics

Product	Ball valve.
Nominal diameter	1/2 - 2 Inch.
Design temp.	Down to -29℃.
Design pressure	Class 150 - 1500 LB.
Material	Carbon Steel.
Design standard	API608.
Face to face	MFG'S.
OPERATION	LEVER
Connection end	BW, Flange, NPTF, SW.
Test standard	API 598.
Package	Plywood
Application	The oil and gas industry
