ASTM A105N Lift Check Valve, 1 Inch, 800 LB, API 602

Name: ASTM A105N Lift Check Valve, 1 Inch, 800 LB, API 602
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Manufacturer of Integral Flange Lift Check Valves in various specifications: 1 Inch (DN25), 800 LB, 2000 PSI. These high-quality valves are compliant with API 602 and BS 5352 standards, constructed from durable Carbon Steel (ASTM A105N) using Forged Steel techniques. Suitable for a wide range of applications, featuring an Integral Raise Flange design.

Request a quote

Detail Information

API 602 Integral Flange Lift Check Valve A105N 1 Inch Carbon Steel Check Valve DN25 600 LB No Oil Degreasing Piston Type

Design Standard: API 602, BS 5352
Body Material: Forged Steel, Carbon Steel, ASTM A105N
Nominal Diameter: 1 Inch, DN25
Pressure: 800 LB, 2000 PSI
End Connection: Integral Raise Flange
Face To Face: ASME B16.10
Test And Inspection: API 598

Item	Carbon steel Check Valve
Type	Piston Check Valve
Certification	ISO 9001, ISO 14001, ISO 18001, CE, TS, API
Brand	VERVO
Model number	H41Y-600LB-DN25
Port Size	1 Inch, DN25
Pressure	600 LB
Temperature	-29 - 425℃
Connection form	Integral Raised Flange
Body material	Carbon steel ASTM A105N
Feature	Easy disassembly and assembly

Product Range

Size: NPS 1/2 - 4 Inch
Pressure: Class 800 - 2500 LB
Material: Forged steel, Alloy 20, Monel, Inconel, Hastelloy
Design: API 602, BS 5352, ASME B16.34
End: SW, NPT, RF or BW
