ASTM A105N Lift Check Valve, 1 Inch, 150 LB, API 602, RF

Name: ASTM A105N Lift Check Valve, 1 Inch, 150 LB, API 602, RF
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Find top-quality carbon steel lift check valves from a renowned maker. This valve is designed for 1-inch size, 150 LB pressure rating, and complies with API 602 standards. With a DN25 size and PN20 pressure rating, it ensures efficient performance. Made from ASTM A105N material, it features an RF flange and a bolted bonnet for secure installation. The integral seat design enhances durability, and it meets ASME B16.10 specifications. Choose this reliable valve for optimal flow control in your industrial applications.

Request a quote

Detail Information

Lift check valve, carbon steel, NPS 1, ASME B16.10, 150 LB, A105N, RF.

Valve description:
Lift check valve, bolted bonnet, raised flanged, integral seat.
Design: API 602.
Body: ASTM A105N
Nominal size: 1 Inch.
Nominal class: 150 LB.
End Connection: RF flange.
Face to face: ASME B16.10.
Test and inspection: API 598.

Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 3 Inch (DN15 - DN80).
End connection: BW, Flanged.
Pressure range: Class 150 - 2500 LB (PN16 - PN420).
Working temperature: -29℃ - +429℃.

Technical parameters and characteristics

Product	Lift check valve.
Nominal diameter	1/2 Inch - 3 Inch.
Design temp.	Down to -29℃.
Design pressure	Class 150 - 2500 LB.
Material	Carbon Steel.
Design standard	API 602.
Face to face	ASME B16.10.
Connection end	BW, Flange.
Test standard	API 598.
Package	Plywood
Application	Block reverse flows
