ASME B16.34 Globe Valves, A182 F91, 1-1/2 IN, 1500 LB, OS&Y

Name: ASME B16.34 Globe Valves, A182 F91, 1-1/2 IN, 1500 LB, OS&Y
SKU: GLV-20250830
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a leading alloy steel globe valve manufacturer in China, we produce high-performance valves designed to ASME B16.34 standards for demanding industrial applications. This 1-1/2 inch model features a durable ASTM A182 F91 body, providing excellent strength and corrosion resistance. Rated at Class 1500 LB, it ensures reliable operation under high-pressure conditions. The valve is configured as OS&Y with a pressure seal bonnet for enhanced sealing and safety. Equipped with socket welding ends, it offers secure and efficient installation, making it ideal for critical applications in power plants, oil and gas, and chemical industries.

Request a quote

Detail Information

Valve Description:
Pressure Seal Bonnet Globe Valve, A182 F91, Socket Welding, Bare Shaft, OS&Y.
Design: ASME B16.34
Body: ASTM A182 F91
Nominal Size: 1-1/2 Inch
Nominal Class: 1500 LB
End Connection: ASME B16.11
Face to Face: MFG'S
Test and Inspection: API 598

Product Range:
Body Material: Alloy Steel
Normal Diameter: 1/2 Inch - 4 Inch (DN 15 - DN 100)
End Connection: FLANGE, BW, SW, NPT
Pressure Range: 900 LB-2500 LB (PN160 - PN420)
Working Temperature: -29°C - 500°C

Technical Parameters And Characteristics:

Product Item	Globe Valve
Nominal Diameter	1/2 Inch -4 Inch
Design Temp.	Down to -29°C
Design Pressure	PN160 - PN420
Material	Alloy Steel
Design standard	ASME B 16.34
Face to face	MFG’S
Connection end	FLANGE, BW, SW, NPT
Test standard	API 598
Package	Plywood
Application	water, oil and gas
Certificate	ISO 9001, ISO 14001, ISO 45001, CE
