API 602 Gate Valve, ASTM A105N, Extended Stem, 2 Inch, 300 LB

Name: API 602 Gate Valve, ASTM A105N, Extended Stem, 2 Inch, 300 LB
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Discover top-quality API 602 gate valves from a reliable provider. Our valves are 2 inches in size, suitable for DN50 specifications, with a pressure rating of 300 LB or PN50. Crafted from durable ASTM A105N carbon steel, these valves feature a bolted bonnet, a 100mm stem extension, and RF integral flanged ends for seamless integration. Upgrade your industrial processes with precision and reliability.

Request a quote

Detail Information

Gate valve, carbon steel, bolted bonnet, 2-inch, CLASS 300, A105N, stem extension.

Valve description:
Gate valve, bolted bonnet, integral flange, stem extension 100mm.
Design: API 602.
Body: ASTM A105N
Nominal size: 2 INCH.
Nominal class: 300 LB.
End Connection: RF.
Face to face: ASME B16.10.
Test and inspection: API 598.

Product Range:
Body material: Carbon steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: BW, Flanged.
Pressure range: PN16 - PN320 (150 LB - 2500 LB).
Working temperature: -29℃ - +425℃.

Technical parameters and characteristics

Product	Gate valve.
Nominal diameter	1/2 Inch - 32 Inch.
Design temp.	Down to -29℃.
Design pressure	PN16 - PN320.
Material	Carbon steel.
Design standard	API 602.
Face to face	ASME B16.10.
Connection end	BW, Flange.
Test standard	API 598.
Package	Plywood
Application	Water, steam and air
Special requirement	Stem Extension 100mm
