2 Inch Floating Ball Valve, 150 LB, ASTM A216 WCB, API 6D, RF

Name: 2 Inch Floating Ball Valve, 150 LB, ASTM A216 WCB, API 6D, RF
Brand: www.vervovalve.com
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Explore top-quality 2-inch floating ball valves from a leading manufacturer. Engineered for excellence, these valves are DN50-sized, Class 150 LB, PN20-rated, and crafted from durable Carbon Steel (ASTM A216 WCB). Featuring a bolted bonnet, a two-piece design, and an actuator-operated lever, these valves adhere to API 6D standards. With RF end connections, elevate your industrial processes with precision and reliability.

RF Ball Valves 2PC Ball Valves DN50 Ball Valves Class 150 LB Ball Valve PN20 Ball Valve Bolted Bonnet Ball Valves ASTM A216 WCB Ball Valve 2 Inch Ball Valves API 6D Ball Valve Carbon Steel Ball Valves

Detail Information

Floating ball valve, carbon steel, bolted bonnet, NPS 2, 150 LB, WCB, two pieces.

Valve description:
Design: API 6D.
Body: ASTM A216 WCB
Nominal size: 2 Inch.
Nominal class: 150 LB.
End Connection: RF.
OPERATION: Lever, actuator
Face to face: ASME B16.10.
Test and inspection: API 598.

Product Range:
Body material: Carbon Steel.
Normal diameter: 1/2 - 32 Inch (DN15 - DN800).
End connection: BW, Flange.
Pressure range: Class 150 - 2500 LB (PN16 - PN420).
Working temperature: -29℃ - +429℃.

Technical parameters and characteristics

Product	Ball valve.
Nominal diameter	1/2 - 32 Inch.
Design temp.	Down to -29℃.
Design pressure	Class 150 - 2500 LB.
Material	Carbon Steel.
Design standard	API6D.
Face to face	ASME B16.10.
OPERATION	LEVER, actuator
Connection end	BW, Flange.
Test standard	API 598.
Package	Plywood
Application	The oil and gas industry
