Integral Flanged Globe Valve, A105, 1/2-2 Inch, 900-1500 LB

Name: Integral Flanged Globe Valve, A105, 1/2-2 Inch, 900-1500 LB
SKU: VF-231213-GLV-07
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Elevate your fluid control systems with our ASME B16.34 and BS 5352 compliant Globe Valves, expertly crafted in our Chinese mill. Ranging from 1/2 to 2 inches and available in DN15-DN50 sizes, these valves are built from high-quality ASTM A105 material. Engineered for Class 900-1500 LB and PN150-PN250 services, they offer robust performance under varying pressures. The Bolted Bonnet design ensures secure containment, while the Integral Flanged configuration adds versatility to installation.

Request a quote

Detail Information

Design Construction:
Design: ASME B16.34, BS 5352
Size: 1/2 Inch, 3/4 Inch, 1 Inch, 1-1/4 Inch, 1-1/2 Inch, 2 Inch, DN15, DN20, DN25, DN32, DN40, DN50
Class: 900 LB, 1500 LB, PN150, PN250
Testing: API 598
Face to face: ASME B16.10
Flanges: ASME B16.5
Spiral wound gasket
Integral backseat
Integral body flanges
Marking MSS SP25
Outside Screw and Yoke (OS & Y)
Loose disc stem assembly
Self aligning two piece packing gland
Ratings:
- carbon steel class 800 1975 psig @ 100°F 138 bar + 38°C
- carbon steel class 1500 3705 psig @ 100°F 255 bar + 38°C

More Body Materials:
ASTM A105, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A350 LF2, ASTM A182 F11, ASTM A182 F22, ASTM A182 F5, ASTM A182 F51, ASTM A182 F321.
