BS 5352 Ball Valve, ASTM A182 F316L, 1/2-2 IN, 150-600 LB, RF

Name: BS 5352 Ball Valve, ASTM A182 F316L, 1/2-2 IN, 150-600 LB, RF
SKU: VF-231214-BV-06
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a reputable producer of industrial valves, we proudly present the ASTM A182 F316L Ball Valve, designed to meet the highest standards of performance and reliability. This valve, manufactured in accordance with BS 5352, API 602, and ASME B16.34, is a versatile solution for a wide range of applications. With sizes ranging from 1/2 to 2 inches and available in Class 150 to 600 LB ratings, this ball valve offers flexibility to suit various operational requirements.

Request a quote

Detail Information

Design Construction:
Materials: ASTM A182 F316L
Design: API 602, ASME BI6.34, BS 5352
Testing: API 598
Size: 1/2 Inch, 3/4 Inch, 1, 1-1/4 Inch, 1-1/2 Inch, 2 Inch, DN15, DN20, DN25, DN32, DN40, DN50
Class: 150 LB, 300 LB, 400 LB, 600 LB, PN20, PN50, PN63, PN100
Face to face: ASME B16.10
Flanges: ASME B16.5
Marking MSS SP25
Spiral-wound gasket
Integral backseat
Integral body flanges
Outside Screw and Yoke (OS&Y)
Self aligning two piece packing gland

Ratings:
-carbon steel class 150 285 psig@ 100°F 20 bar + 38°C
-carbon steel class 300 740 psig@ 100°F 51 bar + 38°C

More Body Materials:
ASTM A105, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A350 LF2, ASTM A182 F11, ASTM A182 F22, ASTM A182 F5, ASTM A182 F51, ASTM A182 F321.

Quality Assurance (QA):
Every step from procurement through production, welding, assembly, testing, and packaging is in accordance with quality programs and procedures (ASME Section III manual and ISO 9001 manual).
