ASTM A182 F316L Gate Valve, 1-1/2 IN, 150 LB, NO.12 Trim, RF

Name: ASTM A182 F316L Gate Valve, 1-1/2 IN, 150 LB, NO.12 Trim, RF
SKU: VF-231212-FSGV-18
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Explore our top-tier gate valve factory specializing in ASTM A182 F316L Gate Valves. Crafted under DIN 3352 standards, these forged steel valves boast a NO.12 Trim, 1 1/2-inch size, and Class 150 LB rating. With RF End connections, DN40 sizing, PN20 pressure class, and a convenient Hand Wheel Operator, these gate valves guarantee reliable performance.

Request a quote

Detail Information

Standard: DIN 3352
Material: ASTM A182 F316L
Trim: NO.12
Size: 1 1/2 Inch
Class Rate: 150 LB
Ends: RF
Operating: Hand Wheel
Wall Thickness: API 602, ASME B16.34.
Face-to-face Dimensions for Flanged Valves: ASME B16.10.
Flange Design: ASME B16.5.
Socket Weld Ends to ASME B16.11.
Screwed Ends (NPT) to ASME B1.20.1.
Butt Welding Ends: ASME B16.25.
Pressure Testing: API 598.

More Body Materials:
ASTM A105, ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316, ASTM A182 F316L, ASTM A350 LF2, ASTM A182 F11, ASTM A182 F22, ASTM A182 F5, ASTM A182 F51, ASTM A182 F321.

Quality Assurance (QA):
Every step from procurement through production, welding, assembly, testing, and packaging is in accordance with quality programs and procedures (ASME Section III manual and ISO 9001 manual).
