API 602 Globe Valve, ASTM A105N, 2 Inch, Class 2500 LB, BW
Model Number: VF-240221-FSGBV-02
Key Specifications / Features
Discover precision-crafted forged steel ASTM A105N globe valves from our esteemed manufacturing facility. Engineered to excel in demanding environments, our 2-inch valves boast a Class 2500 LB rating, meeting API 602, BS 5352, and ASME B16.34 standards. Featuring a reduced port design, these valves ensure optimal flow control and efficiency.
Detail Information
Standard: API 602, BS 5352, ASME B16.34
Material: ASTM A105
Size: 2 Inch, DN50
Pressure: Class 2500 LB, PN420
End Connection: BW
Port: Reduce Bore
Operating: Handwheel
Test & Inspection: API 598
Face to Face: ASME B16.10
Seat: RPTFE, PPL, Nylon
Suitable Medium: Water, Natural Gas, Oil and some corrosive liquid
Working Temperature: -29℃ – 425℃
Material: ASTM A105
Size: 2 Inch, DN50
Pressure: Class 2500 LB, PN420
End Connection: BW
Port: Reduce Bore
Operating: Handwheel
Test & Inspection: API 598
Face to Face: ASME B16.10
Seat: RPTFE, PPL, Nylon
Suitable Medium: Water, Natural Gas, Oil and some corrosive liquid
Working Temperature: -29℃ – 425℃
