Y Type Globe Valve
Key Specifications / Features
Detail Information
Full Port or Standard Port.
Outside Screw and Yoke (OS & Y).
Bolted Bonnet with spiral-would gasket, welded bonnet and pressure sealed bonnet.
Integral Backseat, Loose solid disc.
Specifications:
Nominal diameter: 1/2 Inch - 24 Inch (DN15-DN600).
Pressure range: Class 150 - 2500 LB (PN10-PN420).
End connection: BSP, NPT, RF, RTJ, BW.
Working temperature: -29℃ - 650℃.
Body material: Carbon steel, stainless steel, alloy steel.
Operation: Handwheel, gear box, electric, etc.
Design, Manufacturing Standard: API 602, ASME B16.34.
Face To Face: ASME B16.10, DIN 3202, EN 558-1, ISO 5752.
Welding Ends: ASME B16.25, EN 12627.
Flange Connection: ASME B16.5, EN 1092-1, DIN 2543 - DIN 2550.
Test, Inspection: API 598, ISO 5208, BS 6755, EN 12266, DIN 3230.
Remarks conform to MSS-SP-25.
Adopt the following structure:
Taper sealing disc or soft seal structure.
Self-centering gland Bolted bonnet, spiral would eight-square gasket sealing bonnet or pressure seal bonnet.
According to the follow standard:
Flange ends conform to ASME B16.5, ASME B16.47A.
Butt-welding ends conform to ASME B16.25.
Face to face dimension conform to ASME B16.10.
Operation type: Hand wheel, worm gear, bevel gear, electrical, pneumatic and hydraulic, etc.
Applicable Medium Water, oil, gas and other causticity medium (Different raw material for different medium).
Outside Screw and Yoke (OS & Y).
Bolted Bonnet with spiral-would gasket, welded bonnet and pressure sealed bonnet.
Integral Backseat, Loose solid disc.
Specifications:
Nominal diameter: 1/2 Inch - 24 Inch (DN15-DN600).
Pressure range: Class 150 - 2500 LB (PN10-PN420).
End connection: BSP, NPT, RF, RTJ, BW.
Working temperature: -29℃ - 650℃.
Body material: Carbon steel, stainless steel, alloy steel.
Operation: Handwheel, gear box, electric, etc.
Design, Manufacturing Standard: API 602, ASME B16.34.
Face To Face: ASME B16.10, DIN 3202, EN 558-1, ISO 5752.
Welding Ends: ASME B16.25, EN 12627.
Flange Connection: ASME B16.5, EN 1092-1, DIN 2543 - DIN 2550.
Test, Inspection: API 598, ISO 5208, BS 6755, EN 12266, DIN 3230.
Remarks conform to MSS-SP-25.
Adopt the following structure:
Taper sealing disc or soft seal structure.
Self-centering gland Bolted bonnet, spiral would eight-square gasket sealing bonnet or pressure seal bonnet.
According to the follow standard:
Flange ends conform to ASME B16.5, ASME B16.47A.
Butt-welding ends conform to ASME B16.25.
Face to face dimension conform to ASME B16.10.
Operation type: Hand wheel, worm gear, bevel gear, electrical, pneumatic and hydraulic, etc.
Applicable Medium Water, oil, gas and other causticity medium (Different raw material for different medium).
Send your message to this supplier
FAQs
OS&Y stands for Outside Screw and Yoke. This design places the threaded stem outside the valve body, with the yoke supporting the stem. It allows users to visually verify whether the valve is open or closed by observing the stem’s position.
OS&Y gate valves are commonly used in fire protection systems, including sprinklers, hydrants, and standpipes, due to their reliability and clear open/close indication.
