UHF Scrambler Walkie Talkie TC-P10W
Key Specifications / Features
China UHF Scrambler Walkie Talkie Manufacturer Truest provides Walkie Talkie with earpiece, UHF Scrambler, Voice Prompt, High Capacity Li-ION Battery Pack.
Request a quote
Detail Information
Main Features:
1. Busy Channel Lock.
2. Monitor Function.
3. CTCSS,DCS.
4. Voice Scrambler.
5. Voice Prompt.
6. 2200Mah High Capacity Li-ION Battery Pack.
Technical Specifications:
General:
1. Frequency range: 400-480MHZ.
2. Frequency combination: Phase lock loop frequency synthesize.
3. Memory Channels: 16 Channels.
4. Operating Voltage: DC 7.4V.
5. Channel Spacing: 12.5/25KHz.
6. Battery Capacity: 2200MAH (Li-ion battery).
7. Frequency Stability: ±2.5PPM.
8. CTCSS/DSC: CTCSS:50; DCS:105; Selectable.
9. Antenna Impedance: 50Ω.
10. Operating Temperature: -10℃to +60℃.
11. Weight(approx.): 290g (Exceptbattery and antenna).
12. Dimension(approx.): 130×59×37.5mm (Except Antenna).
Transmitter (Testing under TIA/EIA-603 standard):
1. Output Power: 10W (High),5W (Low).
2. Modulation Mode: 16K F3E.
3. MAX. Frequency Deviation: ≤±5.0KHz.
4. Frequency Stability: ±5ppm.
5. Spurious Radiation: ≤60dB.
6. Residual Modulation: ≤-35dB.
7. Modulation: ≤5%(300-3000Hz).
8. FM Noise: ≤-40dB.
9. Audio Distortion: ≤5%.
10. CTCSS Frequency Deviation: 0.75KHz±50Hz.
Receiver (Testing under TIA/EIA-603 standard):
1. Sensitivity: ≤0.20uV.
2. Operating Bandwidth: ≥±7KHz.
3. Squelch Sensitivity: ≤0.15uV.
4. Frequency Stability: ±5ppm.
5. Adjacent channel selectivity: ≥60dB.
6. Spurious Rejection: ≥60dB.
7. Intermodulation Rejection: ≥60dB.
8. FM Noise: ≤-45dB.
9. Audio Power: ≥600mW.
10. Audio Distortion: <5%.
1. Busy Channel Lock.
2. Monitor Function.
3. CTCSS,DCS.
4. Voice Scrambler.
5. Voice Prompt.
6. 2200Mah High Capacity Li-ION Battery Pack.
Technical Specifications:
General:
1. Frequency range: 400-480MHZ.
2. Frequency combination: Phase lock loop frequency synthesize.
3. Memory Channels: 16 Channels.
4. Operating Voltage: DC 7.4V.
5. Channel Spacing: 12.5/25KHz.
6. Battery Capacity: 2200MAH (Li-ion battery).
7. Frequency Stability: ±2.5PPM.
8. CTCSS/DSC: CTCSS:50; DCS:105; Selectable.
9. Antenna Impedance: 50Ω.
10. Operating Temperature: -10℃to +60℃.
11. Weight(approx.): 290g (Exceptbattery and antenna).
12. Dimension(approx.): 130×59×37.5mm (Except Antenna).
Transmitter (Testing under TIA/EIA-603 standard):
1. Output Power: 10W (High),5W (Low).
2. Modulation Mode: 16K F3E.
3. MAX. Frequency Deviation: ≤±5.0KHz.
4. Frequency Stability: ±5ppm.
5. Spurious Radiation: ≤60dB.
6. Residual Modulation: ≤-35dB.
7. Modulation: ≤5%(300-3000Hz).
8. FM Noise: ≤-40dB.
9. Audio Distortion: ≤5%.
10. CTCSS Frequency Deviation: 0.75KHz±50Hz.
Receiver (Testing under TIA/EIA-603 standard):
1. Sensitivity: ≤0.20uV.
2. Operating Bandwidth: ≥±7KHz.
3. Squelch Sensitivity: ≤0.15uV.
4. Frequency Stability: ±5ppm.
5. Adjacent channel selectivity: ≥60dB.
6. Spurious Rejection: ≥60dB.
7. Intermodulation Rejection: ≥60dB.
8. FM Noise: ≤-45dB.
9. Audio Power: ≥600mW.
10. Audio Distortion: <5%.
