High Power UHF Walike Talkie TC-8W
Model Number: TC-8W
Key Specifications / Features
China Walike Talkie Manufacturer Truest produces High Power Walike Talkie for construction site, with Flashlight, Voice Prompt, low power reminding.
Contact Supplier
Detail Information
Main Features:
1. Busy Channel Lock.
2. Battery Save.
3. Monitor.
4. Flashlight.
5. CTCSS,DCS.
6. TOT.
7. Low Power Remind.
8. Voice Prompt.
9. 3000mAh High Capacity Lithium Polymer Battery Pack.
1. Busy Channel Lock.
2. Battery Save.
3. Monitor.
4. Flashlight.
5. CTCSS,DCS.
6. TOT.
7. Low Power Remind.
8. Voice Prompt.
9. 3000mAh High Capacity Lithium Polymer Battery Pack.
| General Specification | |||
| Frequency Range | 400-470MHZ | Frequency combination | Phase lock loop frequency synthesize |
| Memory Channels | 16 Channels | Operating Voltage | DC7.4V |
| Channel Spacing | 12.5/25KHz | Battery Capacity | 3000MAH (Lithum Polymer battery) |
| Frequency Stability | ±2.5PPM | CTCSS/DSC | CTCSS:50 DCS:105 Selectable |
| Antenna Impedance | 50Ω | Operating Temperature | -10℃ to +60℃ |
| Weight (approx.) | 268g (Except battery and antenna ) | Dimension (approx.) | 136×56×40mm (Except Antenna) |
| Transmitter (Testing under TIA/EIA-603 standard) | |||
| Output Power | 8W (High),3W(Low) | Modulation Mode | 16KF3E |
| MAX. Frequency Deviation | ≤±5.0KHz | Frequency Stability | ±5ppm |
| Spurious Radiation | ≤60dB | Residual Modulation | ≤-35dB |
| Modulation Distortion | ≤5% (300-3000Hz) | FM Noise | ≤-40dB |
| Audio Distortion | ≤5% | CTCSS Frequency Deviation | 0.75KHz±50Hz |
| Receiver(Testing under TIA/EIA-603 standard) | |||
| Sensitivity | ≤0.20uV | Operating Bandwidth | ≥±7KHz |
| Squelch Sensitivity | ≤0.15uV | Frequency Stability | ±5ppm |
| Adjacent channel selectivity | ≥60dB | Spurious Rejection | ≥60dB |
| Intermodulation Rejection | ≥60dB | FM Noise | ≤-45dB |
| Audio Power | ≥600mW | Audio Distortion | <5% |
